Place of Origin:
China
Brand Name:
Panlink
Certification:
ISO 9001: 2015, CE
Model Number:
PSR-T12S-10
Document:
| Circuits | 6 for Signal Transmission |
| Electrical Specifications | |
| Voltage Rating | 48VDC |
| Current Rating | 2A |
| Insulation Resistance | Max 200MΩ @ 500VDC |
| Dielectric Noise | 250VAC @ 50Hz, 60s |
| Electric Noise | Max 10mΩ |
| Lead Cable | AWG#26 Teflon Wire |
| Mechanical Specifications | |
| Rotating Speed | 300rpm |
| Operating Temperature | -4℉ to +356℉ (-20℃ to +180℃) |
| Storage Temperature | -13℉ to +374℉ (-25℃ to +190℃) |
| Operating Humidity | 0~95%RH |
| Torque max. | 0.1 N•m |
| Contact Material | Precious Metal |
| Housing Material | Aluminum Alloy |
| Protection Degree | IP54 (higher or lower on request) |
