Custom Slip Rings Tailored To Any Channel Count, Power Level, Data Rate, Environmental Challenge, Or Mounting Requirement
Custom Slip Ring
For specialized and cutting-edge motion control systems, a custom slip ring or rotary interface solution is indispensable. With many years of experience and a powerful R&D team, Panlink has become a global leader in rotary joints. Panlink is capable of providing the following custom solutions:
• Up to 800 channels for complex systems
• High power capability: voltage up to 10,000VAC, current up to 1000A per channel
• Mature communication and sensitive signal transmission technology, with high-speed data transfer rates
up to 40 Gb/s
• Integrated solutions for fiber optic, electrical, RF, and fluid/gas channels
• Large size solutions: optional carbon brush, large pancake, and large through-bore configurations
• Solutions for special environments: high temperature, high pressure, high vibration, or explosion-proof
• Custom mounting requirements: available special configurations and other devices mounting service
• Multi-slip ring combination solutions: integrate up to 8 or more slip rings in a system to provide a
complete rotary interface
• Capable of meeting special parameter requirements for military, marine, or special industrial equipment
 |
PSR-TS85-30P3S |
|
|
Multi-Way: |
33 | |
|
High Voltage: |
500VAC | |
|
Current: |
130A/ Way |
|
|
Key Dimension: |
OD 496mm, Length 1570mm |
|
|
Application: |
Automobile manufacture |
|
|
Combination of Power and Signal |
||
|
Multi-Way: |
4 |
|
High Voltage: |
380VAC | |
|
Current: |
2A/ Way | |
|
High Speed: |
Up to 4,000rpm |
|
|
Application: |
Industry |
|
PSR-T168-20 |
|
|
Multi-Way: |
33 | |
|
High Voltage: |
500VAC | |
|
Current: |
130A/ Way | |
|
Key Dimension: |
ID 168mm, OD 168mm, Length 1060mm |
|
|
Application: |
Environmental treatment |
|
|
Multi-Way: |
180 |
|
High Voltage: |
500VAC | |
|
Current: |
30A/ Way | |
|
Field: |
Military standard |
|
|
Combination of Power, Signal, Coaxial and Fiber |
||
|
Multi-Way: |
40 |
|
High Voltage: |
220VAC | |
|
Current: |
10A/ Way | |
|
Key Dimension: |
OD 496mm, Length 1570mm |
|
|
Application: |
Automobile manufacture |
|
|
Combination of Power, Signal, Coaxial, Encoder and Fiber |
||
|
Multi-Way: |
14 |
|
High Voltage: |
220VAC | |
|
Current: |
10A/ Way | |
|
Key Dimension: |
Thickness 13mm |
|
|
Field: |
Military standard |
|
|
Combination of Power and Signal |
||
|
Multi-Way: |
100 |
|
High Voltage: |
220VAC | |
|
Current: |
20A/ Way | |
|
Application: |
Armored Vehicles/ Turrets |
|
|
Filed: |
Military standard |
|
|
Combination of Power, Signal, Coaxial and Fiber |
||
|
Multi-Way: |
100 |
|
High Voltage: |
220VAC | |
|
Current: |
20A/ Way | |
|
Application: |
Armored Vehicles/ Turrets |
|
|
Filed: |
Military standard |
|
|
Combination of Power, Signal, Coaxial and Fiber |
||
|
Multi-Way: |
30 |
|
High Voltage: |
500VAC | |
|
Current: |
30A/ Way | |
|
Application: |
Marine (underwater up to 2000m) |
|
|
Filed: |
Military standard |
|
|
Feature: |
Oil filled |
|
|
Combination of Power, Signal, Coaxial and Fiber |
||
|
Multi-Way: |
20~100 |
|
High Voltage: |
380VAC | |
|
Current: |
20A/ Way | |
|
Application: |
Industry servo-motor |
|
|
Combination of Power, Signal, Coaxial and Fiber |
||
|
Multi-Way: |
12~40 |
|
High Voltage: |
380VAC | |
|
Current: |
20A/ Way | |
|
Application: |
Wind energy/ Industry |
|
|
Protection Level: |
IP67 | |
|
Combination of Power and Signal |
||
|
Multi-Way: |
12~40 |
|
Type: |
Connector type |
|
|
Application: |
Industry | |
|
Combination of Power and Signal |
||
|
Multi-Way: |
12~40 |
|
Application: |
Industry | |
|
Hybrid air/ water/ power/ signal |
||
|
Multi-Way: |
108 |
|
High Voltage: |
220VAC | |
|
Current: |
20A/ Way | |
|
Field: |
Military standard with compact size |
|
|
Application: |
Aviation tester |
|
|
Combination of Power, Signal and Coaxial |
||
|
Multi-Way: |
12 |
|
High Voltage: |
6000 | |
|
Current: |
20A/ Way | |
|
Temperature: |
Down to -55℃ |
|
|
Altitude: |
Up to 20,000m |
|
|
Field: |
Military standard with compact size |
|
|
Application: |
Aviation tester |
|
|
Combination of Power, Signal and Fiber |
||
|
Multi-Way: |
20 |
|
High Voltage: |
500VAC | |
|
Current: |
30A/ Way | |
|
Key Dimension: |
ID 800mm | |
|
Application: |
Industry |
|
Multi-Way: |
14 |
|
High Voltage: |
380VAC | |
|
Current: |
120A/ Way | |
|
Type: |
Pancake Type | |
|
Key Dimension: |
ID 1200mm | |
|
Application: |
CT/ Industry | |
|
Combination of Power, Signal and High Speed Data up to 4G Bits/s |
||
