Place of Origin:
China
Brand Name:
Panlink
Certification:
ISO 9001: 2015, CE
Model Number:
PSR-TS-6P70S
Document:
| Circuits | 5 for Power Transmission, 47 for Signal Transmission |
| Electrical Specifications | |
| Voltage Rating | 300VAC/40VDC |
| Current Rating | Power: 8A, 4A, Signal: 2A |
| Insulation Resistance | Max 100MΩ @ 250VDC |
| Dielectric Noise | 1500VAC @ 50Hz, 60s |
| Electric Noise | Max 5mΩ |
| Dynamic Resistance | Max 25mΩ @0.1A, 1KHz, 25rpm |
| Crosstalk | -35dB |
| Lead Cable | PTFE |
| Mechanical Specifications | |
| Working Life | 10 million revolutions |
| Rotating Speed | 50rpm |
| Operating Temperature | -22℉ to +158℉ (-30℃ to +70℃) |
| Storage Temperature | -40℉ to +176℉ (-40℃ to +80℃) |
| Operating Humidity | 0~85%RH |
| Torque | 0.2 N•m |
| Vibration | MIL-STD-810G |
| EMI/EMC | MIL-STD-461G |
| Contact Material | Precious Metal |
| Housing Material | Aluminum Alloy |
| Protection Degree | IP53(higher or lower on request) |
| Surface Finish | Sulfuric Acid Anodizing |
| Weight | 2kg |
