Place of Origin:
China
Brand Name:
Panlink
Certification:
ISO 9001: 2015, CE
Model Number:
PSR-CM-9
High-Performance Power & Signal Transmission, Medical-Grade Reliability, Harsh Environment Adaptability, Globally Compliant & Customizable Surgical Table Slip Ring
Medical Surgical Table Slip Ring
The PSR-CM-9 is specifically designed for medical operating tables. It integrates power and signal transmission capabilities, featuring up to 9 channels: 3 channels for 10A power transmission and 6 channels for signal transmission. Utilizing fiber gold brushes, the PSR-CM-9 ensures high performance and reliability, making it a widely adopted solution in operating tables globally.
| Model | Circuits |
Current (amps) |
Voltage (VAC) |
Size (mm) |
Speed (rpm) |
|
| OD | Length | |||||
| PSR-CM-9 | 9 | 5 | 380 | 22 | 107.9 | 300 |
| Remark: Customization is available for current, voltage, speed, power and data combinations. | ||||||
| Model | PSR-CM-9 |
| Housing Material | Engineer plastics |
| Contact Material | Precious metal |
| Lead Wire | Terminal connector |
| Bearing | Precision ball bearings |
| Weight | 0.2Kg |
| Voltage Rating | 380VAC |
| Current Rating | 2A |
| Insulation Resistance | 1000MΩ @ 500VDC |
| Dielectric Strength | 600VDC @ 50Hz |
| Electrical Noise | 10mΩ @ 6VDC, 50mA, 5rpm |
| Speed | 3000rpm |
| Torque | 4N.cm |
| Protection Level | IP54 |
| Working Temperature | -40℃~+80℃ |
| Mechanical Vibration | MIL-SID-810E |
| Relative Humidity | 60% |
